Analisi comparativa ai SoC wireless di Silicon Labs Jul 07, 2022

Silicon Labs è stato attivo nel SoC wireless ultimamente. Ha lanciato EFR32FG23 (FG23) nel settembre 2021 e ha rilasciato EFR32BG24 (BG24) ed EFR32MG24 (MG24) nel gennaio 2022. Tutti hanno superato la convalida nei client alfa e sono ora pronti per la spedizione nel mercato aperto.

laboratori di silicio

xFG23 è stato creato per bande sub 1GHz, supporta Wi-SUN e protocolli proprietari . Si tratta delle prime soluzioni wireless sub-GHz al mondo che combinano RF a lungo raggio ed efficienza energetica con sicurezza Arm PSA Level 3 certificata.

xBG24 e xMG24 sono stati costruiti per una frequenza di 2,4 GHz. Mentre entrambi supportano l'accelerazione AI/ML sul lato edge, xBG24 supporta Bluetooth e 2,4 GHz proprietari e xMG24 è il primo SoC wireless Matter-Ready di Silicon Lab. Quest'ultimo estende la funzione multiprotocollo all'estremo incorporando Bluetooth, 2,4 GHz proprietario, Matter, Zigbee e Thread, facilitando agli utenti la creazione di applicazioni IoT interconnesse e interoperabili.

È normale che i nuovi prodotti vengano forniti con aggiornamenti nella configurazione o nelle prestazioni, ecc. Tuttavia, in scenari reali di creazione di applicazioni IoT, è necessario esaminare e scambiare più elementi. A tale scopo, RF-star ha effettuato un'analisi comparativa di tutti i SoC wireless di Silicon Labs nella tabella seguente come riferimento.

Modello di chip

Bande di frequenza

Supporto protocollo

Confezione e dimensioni

Nucleo della CPU

GPIO

Kb flash

KB di RAM

Versione BT Rete BLE

Gamma di potenza in uscita

Sensibilità RX (dbm)

Corrente TX

Corrente RX

Sicurezza

Accel.AI/ML _

2,4 GHz

Sub GHz

Questione

Bluetooth

Zigbee

Filo

Proprietario

Wifi

WI-SOLE

EFR32BG24

√

╳

√

╳

√

╳

QFN40 5x5 QFN48 6x6

Cortex-M33 32bit 78MHz

26 28 32

1024 1536

128 256

5.3 √ √

-20~10, 19,5 dBm

-105,7 dBm a 125 kbps GFSK -97,6 dBm a 1 Mbps GFSK -94,8 dBm a 2 Mbps GFSK

5 mA a 0 dBm 19,1 mA a 10 dBm 156,8 mA a 19,5 dBm

4,4 mA a 1 Mbps GFSK

AES-128/256 SHA-1, SHA-2 ECC

√

EFR32BG22

√

╳

√

╳

√

╳

QFN40 5×5
QFN32 4×4
TQFN32 4×4

Cortex-M33
32bit
76.8 MHz

18
26

352
512

5.3
√
√

6 dBm max

-106.7 dBm @125 kbps GFSK
-98.9dBm @1mbps GFSK
-96.2 dBm @ 2mbps GFSK

4.1 mA @ 0 dBm
8.2 mA @ 6 dBm

3.6 mA @1mbps GFSK

AES-128 / 256
SHA-1, SHA-2
ECC
ECDSA+ECDH

╳

EFR32BG21

√

╳

√

╳

QFN32 4x4

Cortex-M33
32bit
80 MHz

512
768
1024

64
96

5.3
√
╳

20dBm max

-97.5 dBm @ 1 mbps GFSK
-94.4 dBm @ 2mbps GFSK
-104.9 dBm @ 125 kbps GFSK

9.3 mA @ 0 dBm
33.8 mA @ 10 dBm

8.8 mA @1 mbps GFSK

AES-128 / 256
SHA-1, SHA-2
ECC
ECDSA+ECDH
J-PAKE

╳

EFR32MG24

√

╳

√

╳

QFN40 5×5
QFN48 6×6

Cortex-M33
32bit
78 MHz

25
26
28
32

1024
1536

128
192
256

5.3
√
√

-20~10, 19.5 dBm

-105.4 dBm @250kbps O QPSK DSSS
-105.7dBm @125kbps GFSK
-97.6 dBm @1mbps GFSK
-94.8 dBm @2mbps GFSK

5 mA @ 0 dBm
19.1 mA @ 10 dBm
156.8 mA @ 19.5 dBm

4.4 mA @1 mbps GFSK
5.1 mA @250 kbps O-QPSK DSSS

AES-128 / 192 / 256
ChaCha20-Poly1305
SHA-1, SHA-2
ECDSA+ECDH
Ed25519
Curve25519
J-PAKE
PBKDF2

√

EFR32MG21

√

╳

√

╳

QFN32 4x4

Cortex-M33
32-bit
80 MHz

512
768
1024

64
96

5.3
√
╳

-20~ 10, 12.5, 20 dBm

-104.5dBm @250 kbps O-QPSK DSSS
-97.5 dBm @1mbps GFSK
-94.4 dBm @2 mbps GFSK
-104.9 dBm @ 125 kbps GFSK

9.3 mA @ 0 dBm
33.8 mA @ 10 dBm

8.8 mA @1 mbps GFSK
9.4 mA @250 kbps O-QPSK DSSS

AES-128 / 256
SHA-1, SHA-2
ECC
ECDSA+ECDH
J-PAKE

╳

EFR32MG12

√

╳

√

╳

QFN48 7x7
QFN68 8x8
BGA125 7x7

Cortex-M4
32-bit
40 MHz

28
31
46
65

512
1024

64
128
256

5.3
√
╳

19dBm, (2.4GHz)
20dBm (Sub GHz)

-94.8 dBm @1mbps GFSK,2.4 GHz
-91.3 dBm @2mbps GFSK, 2.4 GHz
-102.7 dBm @250 kbps DSSS-OQPSK, 2.4 GHz
-126.2 dBm @600 bps, GFSK, 915 MHz
-120.6 dBm @2.4 kbps, GFSK, 868 MHz
-107.4 dBm @4.8 kbps, OOK, 433 MHz
-112.2 dBm @38.4 kbps, GFSK, 169 MHz

8.5 mA @ 0 dBm, 2.4 GHz
35.3 mA @ 14 dBm, 868 MHz

11 mA @250 kbps, DSSS-OQPSK, 2.4 GHz
10.0 mA RX @1 Mbps, GFSK, 2.4 GHz
8.4 mA @38.4 kbps, GFSK, 169 MHz

AES-128 / 256
SHA-1, SHA-2
ECC

╳

EFR32FG23

╳

√

╳

√

╳

√

QFN40 5×5
QFN48 6×6

Cortex-M33
32-bit
78 MHz

22
23
31

128
256
512

32
64

✕
✕
✕

20dBm max.

-98.6 dBm @ 400 kbps 920 MHz 4-GFSK
-125.8 dBm @ 4.8 kbps 915 MHz O-QPSK
-96.9 dBm @ 2 Mbps 915 MHz GFSK
-125.3 dBm @ 2.4 kbps 868 MHz GFSK
-111.5 dBm @ 38.4 kbps 868 MHz FSK
-110.7 dBm @ 100 kbps 433 MHz 2GFSK

25 mA @ 14 dBm,915 MHz
85.5 mA @ 20 dBm, 915 MHz

4.2 mA @920 MHz (400 kbps 4-FSK)
3.8 mA @915 MHz (4.8 kbps O-QPSK)
5.1 mA @915 MHz (2 Mbps GFSK)
3.7 mA @ 868 MHz (2.4 kbps GFSK)
3.7 mA @868 MHz (38.4 kbps FSK)
4.0 mA @433 MHz (100 kbps 2GFSK

AES-128 / 192 / 256
ChaCha20-Poly1305
SHA-1, SHA-2
ECDSA+ECDH
Ed25519
Curve25519
J-PAKE
PBKDF2

╳

EFR32FG22

╳

√

╳

QFN40 5×5
QFN32 4×4

Cortex-M33
32-bit
38.4 MHz

18
26

512

✕
✕
✕

6 dBm max

-102.3 dBm @ 250 kbps O-QPSK DSSS
-98.9 dBm @ 1mbps GFSK
-96.2 dBm sensitivity @2mbps GFSK

4.1 mA @ 0 dBm
8.2 mA @ 6 dBm

3.6 mA @1 Mbps GFSK
3.9 mA @250 kbps O-QPSK DSSS

AES-128 / 256
SHA-1, SHA-2
ECC
ECDSA+ECDH

╳

EFR32FG12

√

╳

√

╳

√

QFN48 7x7
QFN68 8x8
BGA125 7x7

Cortex-M4
32-bit
40 MHz

28
31
46
65

512
1024

64
128
256

✕
✕
✕

20dBm max

-94.8 dBm @ 1mbps GFSK,2.4 GHz
-102.7 dBm @ 250 kbps DSSS-OQPSK, 2.4 GHz
-126.2 dBm @600 bps, GFSK, 915 MHz
-120.6 dBm @ 2.4 kbps, GFSK, 868 MHz
-107.4 dBm @ 4.8 kbps, OOK, 433 MHz
-112.2 dBm @38.4 kbps, GFSK, 169 MHz

8.5 mA @ 0 dBm, 2.4 GHz
35.3 mA @ 14 dBm, 868 MHz

8.4 mA @38.4 kbps, GFSK, 169 MHz
10.0 mA @ 1 Mbps, GFSK, 2.4 GHz
11 mA @250 kbps, DSSS-OQPSK, 2.4 GHz

AES-128 / 256
SHA-1, SHA-2
ECC

╳

EFR32FG13

√

╳

√

╳

QFN32 5x5
QFN48 7x7

Cortex-M4
32-bit
40 MHz

16
28
31
32

512

✕
✕
✕

20dBm max

-94.8 dBm @1mbps GFSK, 2.4 GHz
-102.7 dBm @250 kbps DSSS-OQPSK, 2.4 GHz
-126.2 dBm @600 bps, GFSK, 915 MHz
-120.6 dBm @2.4 kbps, GFSK, 868 MHz
-107.4 dBm @ 4.8 kbps, OOK, 433 MHz
-112.2 dBm @ 38.4 kbps, GFSK, 169 MHz

8.5 mA @ 0 dBm, 2.4 GHz
35.3 mA @ 14 dBm，868 MHz

‘8.4 mA @38.4 kbps, GFSK, 169 MHz
9.5 mA @1mbps, GFSK, 2.4 GHz
10.3 mA @250 kbps, DSSS-OQPSK, 2.4 GHz

AES-1282 / 256
SHA-1, SHA-2
ECC

╳

EFR32FG14

√

╳

√

╳

QFN32 5x5
QFN48 7x7

Cortex-M4
32-bit
40 MHz

16
28
31
32

128
256

16
32

✕
✕
✕

20dBm max

-93.8 dBm @1 mbps GFSK, 2.4 GHz
-103.3 dBm @250 kbps DSSS-OQPSK, 2.4 GHz
-126.2 dBm @600 bps, GFSK, 915 MHz
-120.6 dBm @2.4 kbps, GFSK, 868 MHz
-109.9 dBm @4.8 kbps, OOK, 433 MHz
-112.2 dBm @ 38.4 kbps, GFSK, 169 MHz

8.5 mA @ 0 dBm, 2.4 GHz
35.3 mA @ 14 dBm, 868 MHz

8.4 mA @38.4 kbps, GFSK, 169 MHz
8.8 mA @1 mbps, GFSK, 2.4 GHz
10.2 mA @ 250 kbps, DSSS-OQPSK, 2.4 GHz

AES-128 / 256
SHA-1, SHA-2
ECC

╳

EFR32FG1

√

╳

√

╳

QFN32 5x5
QFN48 7x7

Cortex-M4
32-bit
40 MHz

16
28
31
32

32
64
128
256

8
16
32

✕
✕
✕

20dBm max

-92.5 dBm @1 mbps GFSK, 2.4 GHz
-99 dBm @ 250 kbps DSSS-OQPSK, 2.4 GHz
-126.4 dBm @600 bps, GFSK, 915 MHz
-121.4 dBm @ 2.4 kbps, GFSK, 868 MHz
-107 dBm @4.8 kbps, OOK, 433 MHz
-111.9 dBm @38.4 kbps, GFSK, 169 MHz

8.2 mA @ 0 dBm, 2.4 GHz
34.5 mA @ 14 dBm, 868 MHz

7.6 mA@38.4 kbps, GFSK, 169 MHz
8.7 mA@1mbps, GFSK, 2.4 GHz
9.8 mA@ 250 kbps, DSSS-OQPSK, 2.4 GHz

AES-128 / 256
SHA-1, SHA-2
ECC

╳

Summarized by RF-star @2022
